Comparing Multi-Tenancy Features between Apache Pulsar and Kafka

Comparing Multi-Tenancy Features between Apache Pulsar and Kafka

Software multi-tenancy (or simply multi-tenancy) refers to the fact that a single instance of a software system is able to serve multiple tenants. In a multi-tenancy software system, the usage of the system instance is logically divided among multiple tenants but physically shared on the same underlying infrastructure environment. In contrast, with a single-tenancy system, the usage of the system instance is dedicated to only one tenant both logically and physically.

Compared with a single-tenancy system, the benefits of a multi-tenancy system are obvious, such as 1) simplified system setup, configuration, maintenance, and application deployment; 2) on-going cost savings; 3) easy on-boarding of new customers; and so on and so forth.

For a software system to be considered as having multi-tenancy support, it must satisfy two fundamental requirements within one single system instance:

  1. Security Context – Each tenant should be only able to access its own data. The access to each tenant’s data should always be protected and authorized via necessary security measures such as authentication, authorization, and encryption.
  2. Resource Segregation – When multiple tenants share the same set of infrastructure resources, each tenant, no matter how heavy or light the workload is, should have fair opportunity to use the shared infrastructure resources. Otherwise, some tenants may use up all available resources and therefore starve others.

Apache Pulsar is a true multi-tenancy system that has many built-in mechanisms to support it.

In this article, we’ll compare the multi-tenancy features that are available in both Pulsar and Apache Kafka. Through this comparison it will become clear that Pulsar is a true, robust multi-tenancy system while Kafka has very limited multi-tenancy capability such that it is practically a single-tenancy system.

Note that our discussion about Pulsar and Kafka in this article focuses on their open source software (OSS) releases. The vendor-specific releases and products such as the software-as-a-service (SaaS) offerings are beyond the scope of this article.

Multi-tenancy in Pulsar

Pulsar tenant overview

In Pulsar, tenant is a first-class citizen. By design, messages in Pulsar are published to topics, and topics are organized in a three-level hierarchy structure as shown below.

Figure 1. Three-level hierarchy structure in Apache Pulsar.

With this structure:

  • One tenant represents a specific business unit or a product line. Topics created under a tenant share the same business context that are distinct from others.
  • Within one tenant, topics having similar behavioral characteristics can be further grouped into a smaller administrative unit called a namespace. Different policies such as message retention or expiry policy can be set either at the namespace level or at an individual topic level (more on this later). Polices set at the namespace level will be applicable to all topics under the namespace.

In Pulsar, the name of a topic actually reflects the following structure:

{persistent|non-persistent}://<tenant_name>/<namespace_name>/<topic_name>

When a client application (e.g. a producer or a consumer) connects to a Pulsar topic, it must specify the full string that contains the tenant and the namespace names. Otherwise, an error will be reported about invalid topic names.

Please note that in Pulsar a topic can be persistent (the topic name starts with persistent:// prefix) or non-persistent (the topic name starts with non-persistent:// prefix). In a non-persistent topic, messages are only stored in memory and not persisted to hard drives. Because non-persistent topics are used only rarely in some edge situations, we will not discuss them in this article. For the remainder of this article, I will refer to the persistent topic in Pulsar as simply “topic”.

Pulsar security feature overview

The establishment of the security context for a Pulsar tenant relies on different categories of security features that are available in Pulsar. In this section, I’ll briefly go through these features. In the next section, we’ll see how a tenant’s security context can be properly implemented in Pulsar.

Like many system software applications, the security features in Pulsar fall into three major categories: authentication, authorization, and data encryption.

Authentication

Pulsar supports authentication with pluggable providers. Currently the following authentication providers are supported out of the box:

Customized authentication providers are also possible by extending Pulsar’s authentication API.

In Pulsar, the authentication is responsible for properly identifying a client and associates it with a Role Token which is simply a string name that can be associated with a set of permissions by Pulsar authorization.

Using a JWT authentication example, the following Pulsar CLI command creates a JWT token that expires in one year:

$ bin/pulsar tokens create \

--secret-key file:///path/to/token-generation-secret.key \

--expiry-time 1y \

--subject my-test-role


The generated token (displayed as the CLI output) is associated with a Role Token named my-test-role. Any client that has the generated JWT token can successfully connect to Pulsar.

Authorization

The main purpose of the Role Token that is associated with an authenticated client is for proper Pulsar resource (e.g. a topic) access control when Pulsar authorization is enabled.

The Pulsar admin CLI command below shows an example of granting message publishing privilege (but no message consuming privilege) to my-test-role Role Token for all topics within the namespace my-namespace of the tenant my-tenant:

$ bin/pulsar-admin namespaces grant-permission my-tenant/my-namespace \

--role my-test-role \

--actions produce

In Pulsar, authorization is also pluggable. Out of the box, Pulsar has a built-in authorization provider. However, customized authorization providers can be added by extending Pulsar server authorization API.

Encryption

In Pulsar, data encryption is available as both transport encryption and end-to-end message encryption.

Transport encryption is used to protect the network transmission from being eavesdropped between a client and a Pulsar broker server (and among Pulsar servers) so that sensitive information such as JWT token and credit card information are secured.

For even stronger protection of the message exchange between a producer and a consumer, Pulsar supports end-to-end message encryption (currently supported in the Java client). Simply speaking, the end-to-end message encryption mechanism uses a dynamically generated symmetric AES key, data key, to encrypt and decrypt the messages. The client applications use an asymmetric ECDSA and RSA key pair to encrypt and decrypt the AES data key.

Security context setup for a Pulsar tenant

Establishing a security context for one Pulsar tenant will protect all the message data within this tenant from being accessed by unauthorized users, including those from other tenants. In order to achieve this, we first need to enable the security features in a Pulsar cluster.

Once the Pulsar security is enabled, the security features will be applied the same way to all tenants within the cluster, especially for encryption. From a multi-tenancy perspective, Pulsar supports enabling multiple authentication providers at the same time, so each tenant can use the authentication method of its choice if needed. The main differentiating part of Pulsar security context around tenants is from Pulsar’s authorization mechanism.

Cluster admin role

When enabling authorization in Pulsar, the following configuration parameters need to be set in broker.conf:

authorizationEnabled=true

authorizationProvider=org.apache.pulsar.broker.authorization.PulsarAuthorizationProvider

authorizationAllowWildcardsMatching=[true|false]

superUserRoles=<list of role names>

Through the superUserRoles configuration parameter, a list of role names (separated by comma) can be specified as the Pulsar cluster administrators, or in other words, super-users.

A cluster administrator is able to do all administrative operations such as managing tenants, namespaces, and topics; as well as to publish messages to and consume messages from all topics under all tenants.

Tenant admin role

A cluster administrator can create a tenant with a list of assigned tenant administrators through the following Pulsar admin CLI command:

$ pulsar-admin tenants create <tenant_name> \

--allowed-clusters <list of cluster names> \

--admin-roles <list of role names>

A tenant administrator is able to do all administrative operations within the specific tenant, such as managing the namespaces and the topics within the tenant. It is also able to publish messages to and consume messages from all topics within the tenant.

Allowed clusters for geo-replication

It’s worth mentioning that when there are multiple Pulsar clusters forming a geo-replication use case, Pulsar also has the ability to specify which clusters a particular tenant can access. This is achieved by the --allowed-clusters option when creating the tenant.

  • If this option is not provided, the messages within the tenant are able to be replicated among all available clusters.
  • Otherwise, the messages within the tenant can only be replicated within the specified clusters.

Access control within a tenant

A tenant administrator can define any of the following access control privileges to a role within the tenant:

  • only publishing messages
  • only consuming messages
  • both publishing and consuming messages

The above privileges can be applied at both the namespace level and the individual topic level. When applied at the namespace level, then a user (with the associated role) gets the privileges on all topics within the namespace. Otherwise, the user only gets the privilege on one specific topic

The Pulsar admin CLI commands to grant the access control privileges at both the namespace level and the topic level are as below:

$ pulsar-admin namespaces grant-permission <tenant>/<namespace> \

--role <role_name> \

--actions [produce|consume|produce,consume]

$ pulsar-admin topics grant-permission persistent://<tenant>/<namespace>/<topic> \

--role <role_name> \

--actions [produce|consume|produce,consume]

At the namespace level, the tenant administrator can also grant permissions to a list of roles for a specific subscription, as below:

$ pulsar-admin namespaces grant-subscription-permission <tenant>/<namespace> \

--roles <comma_separated_role_name_list> \

--subscription <subscription_name>

The above access control privileges can also be revoked using corresponding Pulsar admin CLI commands (or Rest API calls).

Access control with Wildcard Role Matching

When enabling Pulsar authorization, if the authorizationAllowWildcardsMatching parameter is set to true, the access control privileges can be granted to a set of roles matching a specific pattern. To be specific, in the above CLI command, the --role option can be specified as in one of the following two forms (as examples):

  • *.my.role
  • my.role.*

Note: At the moment, the wildcard matching is only applicable if wildcard-char (*) presents at first or last position.

Pulsar tenant resource utilization and segregation

In Pulsar, there are an abundance of mechanisms regarding how resource utilization can be controlled and segregated among different tenants.

Resource utilization policies

When messages are processed and stored in Pulsar, they consume the hardware resources – CPU, memory, hard drive, and network bandwidth. Out of the box, Pulsar has provided close to 40 different policies that can be used to impact resource utilization.

The majority of these policies can be set at both the namespace level and the individual topic level; while a few of them are only relevant at the namespace level or at the individual topic level. When a policy is set at both levels, the topic level setting is taking precedence over the one at the namespace level.

These policies can be set by using either Pulsar admin CLI commands or Pulsar Rest APIs. A few of these policies are listed below as an example:

  • set-publish-rate
  • set-retention
  • set-offload-threshold
  • set-max-message-size

For a complete list of these policies and their application levels, refer to Apache Pulsar documentation.

Resource quota

In Pulsar, a more direct resource utilization control mechanism is to set the resource quota, which can be achieved in different ways:

  • message rate on an individual topic
  • message rate on a namespace bundle
  • message rate on a namespace
  • producer and consumer number per topic

Individual topic level message rate

In Pulsar, we can set the rate (either as number of messages or number of bytes) for message publishing, dispatching, or subscription on an individual topic. An example of setting the message publishing rate for a topic using the Pulsar admin CLI command is:

$ pulsar-admin topics set-publish-rate persistent://tenant/namespace/topic \

--byte-publish-rate <byte_rate_number> \

--msg-publish-rate <msg_rate_number>

Namespace bundle quota

In Pulsar, when topics are assigned to brokers, it is not done on an individual topic basis. Instead, each broker takes ownership of a subset of the topics for a namespace. This subset is a namespace bundle. All bundles within a namespace will be assigned to all available brokers as evenly as possible by Pulsar.

Each namespace bundle is relatively an independent unit and we can set the following resource quotas on it:

  • inbound bandwidth (bytes/second)
  • outbound bandwidth (bytes/second)
  • memory usage (Mbytes)
  • inbound message rate (message/second)
  • outbound message rate (message/second)

The Pulsar admin CLI command to set the namespace bundle quota is as below:

$ pulsar-admin resource-quotas set \

--namespace <namespace_name> \

--bundle <bundle_range> \

--bandwidthIn <incoming_message_bytes_number>

--bandwidthOut <outcoming_message_bytes_number> \

--msgRateIn <outcoming_message_number> \

--msgRateOut <incoming_message_number> \

--memory <message_usage_number> \

--dynamic <whether or not to allow dynamic re-calculation>

Namespace level quota

Similar to the individual topic level quota, we can also set a collective rate (either as number of messages or number of bytes) for message publishing, dispatching, or subscription for all topics within a namespace. The example of setting the collective message publishing rate for a namespace using the Pulsar admin CLI command is as below:

$ pulsar-admin namespaces set-publish-rate tenant/namespace \

--byte-publish-rate <byte_rate_number> \

--msg-publish-rate <msg_rate_number>

Producer and consumer number per topic

In Pulsar, we can limit the maximum number of producers and consumers that are allowed to publish to one topic. For consumers, we can even further limit the maximum number of consumers per subscription and the maximum number of unacknowledged messages per consumer. These settings will directly impact the CPU and memory utilization of Pulsar brokers.

Here are examples of how to set these limits in the Pulsar admin CLI:

$ pulsar-admin topics set-max-producers persistent://tenant/namespace/topic \

--max-producers <producer_number>

$ pulsar-admin namespaces set-max-consumers-per-topic tenant/namespace \

--max-consumers-per-topic <consumer_number>

Server isolation

In Pulsar, resource utilization segregation can even be achieved at the server host (broker or bookie) level through broker isolation policy and bookie affinity group.

Broker isolation policy

When assigning topics to brokers, we can use the broker isolation policy to limit the set of brokers that can be used for topic assignment within a set of specified namespaces.

The Pulsar admin CLI command to specify the broker isolation policy is as below:

$ pulsar-admin ns-isolation-policy set <cluster_name> <policy_name> \

--namespaces <comma separated namespaces-regex list> \

--primary <comma separated primary-broker-regex list>

--secondary <comma separated secondary-broker-regex list>

-- <other options> …

We can set the namespace isolation policy with a primary or a secondary regular expression (regex) to select desired brokers. Since a fully qualified namespace name includes the tenant name, we can craft the namespace regex string in a way so that all topics from a specific tenant can be mapped to a separate set of brokers.

If no broker matches the specified regex, we cannot create a topic. If there are not enough primary brokers, topics are assigned to secondary brokers. If there are not enough secondary brokers, topics are assigned to other brokers which do not have any isolation policies.

Bookie affinity group

Similarly, namespaces can also be limited to a subset of bookies for message persistence. This is achieved by assigning bookies to an affinity group as shown in the Pulsar admin CLI command below:

$ pulsar-admin namespaces set-bookie-affinity-group <tenant>/<namespace> \

--primary-group <primary bookie group name> \

--secondary-group <secondary bookie group name>

When the bookie affinity group is set for a namespace, the messages written to a topic that belong to the namespace will be persisted to the specified primary group bookies. If there are not enough bookies in the primary group, messages will be written to the secondary group bookies.

The bookie-group relationship is established when setting up the bookie rackaware policies as follows:

$ pulsar-admin bookies set-bookie-rack \

--bookie <bookie address in format ‘address:port’) \

--hostname <bookie host name> \

--group <bookie group name> \

--rack <bookie rack name>

Comparing Pulsar with Kafka multi-tenancy

According to the Kafka documentation, multi-tenancy support is also possible in Kafka. But when we delve into the details, we can see that the multi-tenancy capability in Kafka is fairly limited and primitive.

Logical topic grouping

In Kafka, the topic structure is flat. There is no built-in hierarchical structure that we can rely on to organize the topics into groups, which is required by multi-tenancy. In order to address this issue, a common practice in Kafka is to define a topic name with some sort of logical, prefix-based structure, such as:

<organization>.<team>.<project>.<topic>

Such a structure is simply a naming convention and nothing more. Any logical component within this structure by itself has no meaning at all in Kafka, and you can do nothing about it such as applying security or resource related policies.

From the multi-tenancy perspective, a big risk associated with such a practice is that anyone with topic creation privileges can create a topic with a name structure in whatever the way they like. This is risky because this person may create a topic that looks like it belongs to a different tenant (assuming the tenancy is marked by the topic prefix).

In order to address the above security concern, Kafka has recommended several best practices:

  • Disable topic auto-creation feature at the broker level (in broker configuration).
  • Deny topic creation privilege for normal users and only allow dedicated administration users or processes to create topics on behalf of normal users.
  • Use prefix ACL (KIP-290) to enforce user access control to Kafka resources, like topics whose names start with a certain prefix pattern (more on this later).

But these practices are not enough to fully remedy the risk associated with Kafka’s flat topic structure.

Kafka security feature recap

Kafka’s built-in security features also fall into similar categories as in Pulsar: authentication, authorization, and transport data encryption.

Authentication

In Kafka, users can be authenticated using either TLS-based authentication or simple authentication and security layer (SASL) based authentication. At the moment, Kafka supports the following SASL-based authentication mechanisms:

  • GSSAPI (Kerberos)
  • PLAIN
  • SCRAM-SHA-256
  • SCRAM-SHA-512
  • OAUTHBEARER

SASL based authentication can be used with PLAINTEXT (SASL_PLAINTEXT) or SSL (SASL_SSL) as the transport layer protocol.

Authorization

When Kafka (broker) authenticates a client, it associates the client with a KafkaPrincipal that represents the client’s identity with the connection. Kafka authorizes the principal associated with the connection and determines what operations are allowed.

Kafka supports pluggable Authorizer with an out-of-box authorizer implementation AclAuthorizer (since Kafka 2.3). Versions older than Kafka 0.9 have a built-in authorizer SimpleAclAuthorizer that has since been deprecated.

AclAuthorizer supports fine-grained access control for Kafka resources using access control lists (ACLs). Each ACL definition consists of the following information:

  • Resource type: Cluster|Topic|Group|TransactionalId|DelegationToken
  • Pattern type: Literal|Prefixed
  • Resource name: Name of resource or prefix or the wildcard *
  • Operation: Describe|Create|Delete|Alter|Read|Write|DescribeConfigs|AlterConfigs
  • Permission type: Allow|Deny (Deny has higher precedence)
  • Principal: Kafka principal represented as <principalType>:<principalName>, For example User:Bob or Group:Sales. ACLs may use User:* to grant access to all users.
  • Host: Source IP address of client connection or * if all hosts are authorized.

Encryption

Transport encryption is a standard procedure to protect in-transit communications between a client and a Kafka broker, between Kafka brokers, and so on. There is no difference between Kafka and Pulsar in terms of the general procedure used. End-to-end message encryption is also possible in Kafka.

Set up security context for a Kafka “tenant”

Traditionally in Kafka, before KIP-290 was introduced, the supported semantics of resource name in ACL definition is either full resource name or special wildcard * that matches everything.

Based on these semantics, the only way to separate the security contexts for different tenants is to repeat defining the same set of ACLs on every single topic that logically belongs to one tenant. For topics belonging to another tenant, a different set of ACLs need to repeat again. Practically speaking, this approach is too cumbersome to be used as a multi-tenancy security context for a Kafka tenant

With KIP-290 (via KAFKA-6841), Kafka introduced prefixed ACLs (since version 2.0). This allows Kafka to define bulk ACLs that match all topic names starting with a certain prefix. For example, an ACL definition might look like: Principal user1 has access to all topics that start with the prefix com.companyA.

Despite being an improvement, this method for separating security contexts for different tenants is still very coarse and primitive.

Kafka tenant resource utilization and segregation

Resource utilization configuration

In Kafka, there are a few topic level configuration items that may indirectly impact resource utilization, such as max.message.bytes, retention.bytes, and retention.ms. You can specify these configurations either when creating a topic (using kafka-topics.sh --config option) or adding/updating them later (using kafka-configs.sh --add-config option).

The problem here is that there are not many of these resource utilization-related configuration items, and it is very hard to relate them with a particular tenant.

Resource quota

In Kafka, the main resource utilization control mechanism is the resource quota, which falls into two main categories: server quota and client quota.

The server quota is applied at broker level that impacts all clients collectively that connect to the broker. An administrator can set these quotas as:

  • rate at which the broker can accept new connections (max.connection.creation.rate)
  • maximum number of connections per broker (max.connections)
  • maximum number of connections allowed from a specific IP (max.connections.per.ip)

The client quota is more relevant with tenant-based resource control and segregation within Kafka. The client quotas can be applied to a user principal, a client-id group, or a combination of both. The client-id is a logical grouping of clients with a meaningful name chosen by the client application.

There are two types of client quotas, One type is network bandwidth quotas that define byte-rate (X bytes/sec) thresholds (since version 0.9). The other is request rate quotas that define CPU utilization thresholds as a percentage of network and I/O threads (since version 0.11).

The client quota is irrelevant with the topics, and all topics from a user group will share the resource quota limitations set on the user group.

In Kafka, there is also no way to limit the number of producers and consumers that are allowed to connect a topic for message publishing and consuming.

Conclusion

Multi-tenancy is an architecture choice desired by many software systems because of its obvious benefits. However, it is also hard to implement, especially in a robust and complete manner.

In this article, we explored and compared the multi-tenancy features of two mainstream messaging and streaming technologies – Apache Pulsar and Apache Kafka. From our comparison, we can see that between the two technologies, the multi-tenancy support in Kafka is rather limited from both security context and resource segregation perspectives.

In contrast, Pulsar is by design, a true, robust multi-tenancy system. The tenant is a first-class citizen concept in Pulsar and sits at the very core of Pulsar’s message processing and management hierarchy. For each tenant, there’s an abundance of built-in policies that can be applied to it to properly protect the tenant’s data integrity and ensure fair resource utilization.

Read more about seven reasons why you should choose Pulsar over Kafka and why Pulsar is essential to the modern data stack.

Follow the DataStax Tech Blog for more developer stories. Check out our YouTube channel for tutorials and here for DataStax Developers on Twitter for the latest news about our developer community.

Resources

  1.  Apache Pulsar
  2.  Apache Kafka
  3.  Pulsar Documentation: Retention Policies
  4.  Pulsar Documentation: Time to live (TTL)
  5.  Pulsar Documentation: Non-persistent messaging
  6.  Transport Layer Security (TLS)
  7.  Athenz
  8.  Kerberos
  9.  JSON Web Token (JWT)
  10. OAuth 2.0
  11. Elliptic Curve Digital Signature Algorithm (ECDSA)
  12. RSA (Cryptosystem)
  13. Apache Pulsar Documentation: Set Up a Standalone Pulsar Locally
  14. Kafka Documentation
  15. Kafka Improvement Proposal (KIP) 290: Support for Prefixed ACLs
  16. KAFKA-6841: Add Support for Prefixed ACLs
  17. DataStax Medium
  18. DataStax YouTube Channel
  19. DataStax Developers on Twitter
  20. Join our Discord: Fellowship of the (Cassandra) Rings
Share

One-stop Data API for Production GenAI

Astra DB gives JavaScript developers a complete data API and out-of-the-box integrations that make it easier to build production RAG apps with high relevancy and low latency.
